Beech Plywood
European Beech Throughout Plywood
Full Pack Volumes
for Commercial Projects
Beech Plywood has technical and decorative values
Used in furniture and applications requiring strength
Sometimes referred to as Multiplex beech panels,
this is ideal for worktops, benches / bench tops and tabletops
Thickness & Packing
| Plywood thickness | No. of plies | Packing |
|---|---|---|
| 4mm | 3 ply | 190 sheets |
| 6mm | 5 ply | 140 sheets |
| 6.5mm | 5 ply | 140 sheets |
| 9mm | 7 ply | 100 sheets |
| 12mm | 9 ply | 50 sheets |
| 15mm | 11 ply | 40 sheets |
| 18mm | 13 ply | 35 sheets |
| 21mm | 15 ply | 30 sheets |
| 24mm | 17 ply | 25 sheets |
| 27mm | 19 ply | 22 sheets |
| 30mm | 21 ply | 20 sheets |
| 35mm | 25 ply | 17 sheets |
Plies are the number of laminations. 1.4mm thick, cross bonded
Request a Quote
Specifications
Face Grades
Our other decorative panels...
Full Packs Only
As importers we are set up for full pack volumes
Beech plywood is a special order item
Allow 8-10 week lead time from order
Alternative Item - In Stock
Thickness
4mm / 6.5mm / 9mm / 12mm / 15mm / 18mm / 21mm / 24mm / 27mm / 30mm / 35mm
Core Options
Beech 100% (Face: Beech / Core: Beech)
Deciduous (Face: Beech / Core: Birch, Alder, Beech)
Combi (Face: Beech / Core: Birch, Alder, Pine, Beech)
Formaldehyde
In accordance with the standard EN 13986 the formaldehyde emission meets the Class E1 requirements (test method EN 717 Part 2)
Moisture Content
10% (+/- 2%) to EN315 and DIN 68705
Weight
750kg per M3*
*approximate and subject to natural variation
Panel Size
2440 x 1220 (8ft x 4ft)
2130 x 1220 (7ft x 4ft)
2500 x 1250
Bonding
EN314-2 class 3 - exterior conditions
previously WBP (Weather and Boil Proof) dark brown glue
Construction
Internal veneers: 1.4mm
External veneers: sanded to 1mm (approx)
I Grade
- equivalent to B grade
- the highest quality plywood
- maximum 3 repair patches (plugs) per M2
- filled unsound knots up to 6mm (2 per M2)
- filled splits up to 1/10th panel length, 3mm wide, (3 per M2)
- slight discolouration permitted
- pin knots permitted, up to 15mm (not more than 30mm cumulative diameter per M2)
III Grade
- equivalent to CP grade
- repair patches (unlimited)
- filled unsound knots & holes up to 40mm
- filled splits up to 1/3 panel length, 20mm wide, (3 per M2)
- slight discolouration permitted
- knots permitted, up to 50mm
- glue penetration up to 5% of panel surface
- sanding through up to 1% of panel surface
- defects at the edges up to 5mm
II Grade
- equivalent to BB grade
- high-quality plywood
- maximum 6 repair patches (plugs) per M2
- filled unsound knots & holes up to 10mm (3 per M2)
- filled splits up to 1/5th panel length, 5mm wide, (3 per M2)
- slight discolouration permitted
- knots permitted, up to 35mm
IV Grade
- equivalent to C grade
- the lowest grade plywood
- not sanded
- open defects of wood structure allowed
- processing defects allowed
- for construction purposes when face grade is not important i.e. packaging
